Name: 16" Zirgo 2803 fCFM High Torque Straight Blade Performance Radiator Cooling Fan
Brand: Zirgo High Performance Cooling Products
SKU: ZIRZFB16
Price: 119.95 USD
Availability: InStock

Ultra Slim Profile

Zirgo® fan's slim profile means it can fit in tight spaces.

Quiet Operation

One of the quietest fans available!

4 Mounts Included

Ensures easy placement for maximum performance.

Push or Pull

Reversible blade design for push or pull air flow.

Product information

REV UP, & COOL DOWN! Zirgo's cooling fans represent the ultimate in cooling technology. Zirgo high-torque fan motors feature sealed ball bearings and fully balanced blades which ensure low noise levels and a long life of smooth operation.

FEATURES:
- 2803 fCFM
- Flat Balanced Blades
- ULTRA SLIM Profile
- Sealed Ball Bearing High-Torque Motor
- Quiet Motor
- Reversible
- 6 mounting Location Options
- 4 Mounts/Feet

To ensure maximum performance, all Zirgo fans offer reversible blades allowing them to operate as pushers or pullers. Zirgo's revolutionary four foot/mount 6 point mounting bracket & ULTRA SLIM PROFILE ensures easy placement for maximum performance on your vehicles cooling system.

Zirgo's unique revolutionary motor designs offer low amp draw and are easily removed from the cage which provides trouble-free future performance upgrades.

Our easy to remove motors also make it possible to reverse air flow! Simply flip the fan and reverse polarity and you are done!

Zirgo's Ultra Thin Design and Unmatchable Performance, along with a Limited Lifetime Warranty, make Zirgo the Optimal Fan for Performance Vehicles. Let Zirgo high performance cooling fans cool you down, when you heat up!

---------------------- :: Performance Cooling Fan
Blade Size :: 16"
Blade Style :: Flat Balanced Blades
Ultra Slim Profile :: Yes
Motor :: Sealed Ball Bearing High-Torque
Amp :: 15A Constant 27A @ Startup
Reversible :: Yes
fCFM :: 2803
Mounting Locations :: 6
Mounts/Feet :: 4
Total Thickness :: 3.5"
Height/Width :: 16.5"
Foot to Foot Max Width :: 17.75" Hole to Hole
Quiet Motor :: Yes
Thin Design :: Yes
Harness :: Available - NOT INCLUDED
Relay Kit :: Available - NOT INCLUDED
Instructions :: Detailed Instructions
Warranty :: Limited Lifetime Warranty

Get Instructions

	Item ID	SKU	UPC
	ZIRZFB16	10210	802269142244

fCFM 2,803

Blade Style Straight Balanced Blades

Blade Size 16 in

Height / Width 16.5 in

Total Thickness 3.5 in

Foot to Foot Max Width 17.75 in

Finish Black

Foot Mounts Included 4 per Fan

Fan Quantity Single (1)

Better Cooling

Superior fCFM

Other fans can't keep up!

The Ultimate in Cooling Technology

Reversible Blades

Reversible blade design for push or pull air flow

Quiet Operation

One of the quietest fans available!

Ultra Thin

Ultra thin fan design fits tight spaces

Take a Closer Look

Mounting Point

4 secure foot mounts included

Quiet Operation

One of the quietest fans available!

Reversible Blades

Reversible blade design for push or pull air flow

Heavy-Duty Motor

Sealed ball bearing high-torque motor

Mounting Point

4 secure foot mounts included

Quiet Operation

One of the quietest fans available!

Reversible Blades

Reversible blade design for push or pull air flow

Heavy-Duty Motor

Sealed ball bearing high-torque motor

Compare with similar items

This item 16" Zirgo 2803 fCFM High Torque Straight Blade Performance Radiator Cooling Fan

10" Zirgo 1019 fCFM High Performance Black Curved “S” Blade Radiator Cooling Fan

10" Zirgo 1149 fCFM High Performance Black Straight Blade Radiator Cooling Fan

12" Zirgo 1248 fCFM High Performance Black Straight Blade Radiator Cooling Fan

14" Zirgo 2122 fCFM High Performance Black Curved “S” Blade Radiator Cooling Fan

Price

$119.95

$79.95

$72.95

$69.95

$99.95

Blade Size

16 in

10 in

12 in

14 in

Blade Style

Straight Balanced Blades

Curved S Blades

Straight Balanced Blades

Curved S Blades

fCFM

2,803

1,019

1,149

1,248

2,122

Finish

Black

Total Thickness

3.5 in

2.31 in

2.5 in

3 in

Foot-Foot Width

17.75 in

12.75 in

11.88 in

13.63 in

16 in

Fan Quantity

Single (1)

Checkout Zirgo's Large Fan Selection

Choose size, blade style, color + more!

Shop Single Fans Shop Complete Fan Kits

FAQs

Is this a puller or pusher fan?

Zirgo® Electric Cooling Fans are designed as a puller, but can be turned into a pusher. See installation instructions for more details.

What is fCFM?

fCFM stands for Forced Cubic Feet per Minute. It measures the volume of air a fan can move.

How do I mount this?

Zirgo® Fans include up to 6 mounting location options. Choose 4 of these and install with included mounting feet for easy placement.

Are the mounting feet included?

Yes, 4 short mounting feet are included.

You can purchase additional short mounting feet here OR long mounting feet here.

Can this be mounted with the pull through plastic fan zip ties?

Yes it can! We recommend Zirgo® Mounting Fan Ties which are the strongest radiator cable ties on the market.

The unique locking design allows for maximum strength with the easiest installation.

*Some kits include Zirgo Mounting Fan Ties. See description for details.

Will this fan fit in my engine bay?

All Zirgo® fans have an ultra slim profile but taking accurate measurements of the engine bay area is crucial to ensure that you select a fan that fits appropriately and does not obstruct other essential components.

Measure the radiator and the distance between the radiator and engine components. Measure the radiator core (the finned surface between the two tanks). You’ll want to select one of our fans that covers as much of this space as possible.

See our Cooling Fan Guide for more information.

Does this fan have a sealed motor and will it survive in a hot engine compartment?

Yes, all Zirgo® fans have a sealed steel water resistant motor. The fan cage is made of heavy duty plastic and will not melt.

Is there a recommended amp fuse for this fan?

Most Zirgo® fans draw around 7.0 amps +/– 0.5 amps. Zirgo® recommends a 30 amp fuse and relay or higher. Shop relays here.

More detailed specifications for each of our fans can be found in our instructions.

Will this fan operate with a 16v system?

Zirgo® fans are designed to run on a 12v system and will not work properly (the motor will quickly burn up) on a 16v system without a voltage reducer.

What accessories do I need?

Check out our Fan Installation Checklist to make sure you've got everything you need to properly cool your ride.

What's the difference between single fans and performance fan packages?

Single Fans - only come with fan and mounting feet.
Performance Fan Packages - come with fan(s), relay, harness, temperature switch, fan ties and mounting feet. Everything you need in 1 box!

What's the difference between universal and vehicle specific fan kits?

Universal Fan Kits - universal fit for most radiators. You can customize for your vehicle if needed.
Vehicle Specific Fan Kits -designed for your car and bolt directly on.

Testimonials

David

This thing cools!

My big block gets hot in town. I put this fan in front of the radiator with a temp solenoid and fan controller… hot engine problem solved!

Malcolm

Great quality

Really happy with the quality - great product. No complaints.

John

I ordered 2 fans!

Both work great and one is already installed in my Hot Rod. I had the same fan on my 31 Model A Blown 355 SBC Coupe before and wanted to use the same one.
