The Zirgo Universal Radiator Temperature Control Kit Puts You in Control Because it Lets You Dial The Exact Temperature You Want Your Fan to Turn On! Perfect For Engines With An Optimal Operating Temperature Greater Than 180 Degrees F (82.2 C).
MORE CONTROL
The adjustable dial allows you to set the fan to turn on anywhere between 180 - 240 Degrees Fahrenheit (82.2 - 115.5 Celsius) so you can be in complete control of your operating temperature.
EASY INSTALLATION
This kit contains everything you need to put you in control of your engine temperature in one convenient Plug -N- Play package! For easy installation this sensor probe can either fit in your water-neck or between the fins on your radiator.
SWITCH FEATURES:
- Adjustable from 180 - 240 Degrees F (82.2 - 115.5 Celsius)
- Analog Input Sensor
- Easy Install Probe
- Mounts in Water-Neck or Between Radiator Fins
- 5 Degree Accuracy
- Measures Fluid Temperature
- Leak Proof Water-Neck Gasket Included
- Mounting Bracket Included
- Wiring Included (OFC Copper Wire)
ADDITIONAL FEATURES
- Plug -N- Play
- Heavy-Duty 40 AMP SPDT Relay w/Mount
- Heavy-Duty Wiring Harness
- Heavy Duty 40 Amp Circuit Breaker w/Mount
Also Available:
- Adjustable Digital Version 0 -240 (115.5 Celsius) SKU: 191655
Zirgo Offers Detailed Instructions, FREE Customer Support and a Limited Lifetime Warranty.
---------- :: ADJUSTABLE TEMP CONTROL SWITCH
Input Sensor :: Analog
Adjustable :: Yes
Measures :: Fluid Temperature
Mounting :: Water-Neck or Between Radiator Fins
Range :: 180-240 Degrees (82.2-115.5 C)
Mounting Bracket :: Included
Water-Neck :: Leak Proof Hose Gasket
Hardware :: Included
Accuracy :: 5 Degrees
Built-In Display :: No
Case :: Heavy-Duty ABS
Activation Light :: No
---------- :: RELAY
Relay Peak Amps :: 40
Voltage :: 12 V DC
Terminals :: 5
Retention Spring :: 2X
Style :: Single Pole/Double Throw
Contacts :: Brass
Tab Height :: 0.625in (19mm
Mounting Style :: Tab Hole .25in (6.3mm)
Terminal Height :: 0.432in (11mm)
Terminal Width :: 0.250in (6mm)
Small Footprint :: Yes
---------- :: Relay Harness
Pins :: 5
Lead Length :: 12in
# of Wires :: 5
Base Material :: Heavy-Duty ABS
Terminals :: Zinc Coated
Wire :: Copper
---------- :: Circuit Breaker
Rating :: 40 Amp
Posts :: 2
Mounting Tabs :: Yes
---------- :: OTHER
Instructions :: Detailed Instructions
Warranty :: Limited Lifetime Warranty
Get Instructions
|
Item ID |
SKU |
UPC |
|
KICHARNAT |
10603 |
802269144606 |
Temperature Switch
Adjustable
Sensor Type
Analog Probe
Turns On
Between 180 - 240 Degrees Fahrenheit
Accuracy
5 Degrees
Temp Switch Mounting Bracket
Included
Relay
40 Amp Included
Relay Terminal Size
1/4 inch Blade Type
Plug n Play Harness
Included
Harness Length
48 in
Harness Wire
14ga
Number of Wires on Harness
4
Fan Quantity
Single (1)
